FPT MARINE DIESEL ENGINE

FPT





FPT Industrial is the company of FIAT Industrial Group dedicated to the development, production and sale of powertrains for FPT Marine Diesel Engine.

The wide range consist of 5 engine families with a power from 50 to 870 HP and transmissions with a maximum power from 300 to 500 Nm.

Commercial Rating

Model B B1 C D Dimension (mm) Dry Weight (kg)
S30 230 E 129 kW (175.5 HP) 3500 RPM 780 x 775 x 753 330
S30 230 E 85 kW (115.6 HP) 3500 RPM 780 x 775 x 753 330
N40 170 125 kW (170 HP) 2800 RPM 850 x 708 x 785 490
N40 170 110 kW (150 HP) 2800 RPM 850 x 708 x 785 490
N40 170 74 kW (100 HP) 2800 RPM 850 x 708 x 785 490
N40 170 63 kW (85 HP) 2800 RPM 850 x 708 x 785 490
N40 250 E 169 kW (230 HP) 2800 RPM 850 x 708 x 785 490
N40 250 E 147 kW (200 HP) 2800 RPM 850 x 708 x 785 490
N40 250 E 110 kW (150 HP) 2800 RPM 850 x 708 x 785 490
N40 250 E 74 kW (100 HP) 2800 RPM 850 x 708 x 785 490
N45 100 66.5 kW (90 HP) 2800 RPM 811 x 700 x 836 450
N45 100 63 kW (85 HP) 2800 RPM 811 x 700 x 836 450
N60 400 E 272 kW (370 HP) 3000 RPM 1072 x 739 x 778 595
N60 400 E 242 kW (330 HP) 3000 RPM 1072 x 739 x 778 595
N60 400 E 198 kW (270 HP) 3000 RPM 1072 x 739 x 778 595
N67 150 99.5 kW (135 HP) 2800 RPM 1052 x 705 x 910 530
N67 150 92 kW (125 HP) 2800 RPM 1052 x 705 x 910 530
N67 170 125 kW (170 HP) 2300 RPM 1089 x 724 x 788 600
N67 220 132 kW (180 HP) 2800 RPM 1072 x 749 x 800 605
N67 220 110 kW (150 HP) 2800 RPM 1072 x 749 x 800 605
N67 280 191 kW (260 HP) 2800 RPM 1072 x 749 x 800 605
N67 280 169 kW (230 HP) 2800 RPM 1072 x 749 x 800 605
N67 280 132 kW (180 HP) 2500 RPM 1072 x 749 x 800 605
N67 450 N 309 kW (420 HP) 3000 RPM 1089 x 724 x 788 600
N67 450 N 272 kW (370 HP) 3000 RPM 1089 x 724 x 788 600
N67 450 N 257 kW (350 HP) 3000 RPM 1089 x 724 x 788 600
N67 550 368 kW (500 HP) 3200 RPM 1089 x 850 x 825 721
N67 550 353 kW (480 HP) 3200 RPM 1089 x 850 x 825 721
N67 570 EVO 390 kW (530 HP) 3000 RPM 1089 x 847 x 825 721
N67 570 EVO 357 kW (485 HP) 3000 RPM 1089 x 847 x 825 721
C90 380 301 kW (410 HP) 2000 RPM 1288 x 868 x 961 940
C90 380 279 kW (380 HP) 2000 RPM 1288 x 868 x 961 940
C90 620 E 426 kW (580 HP) 2530 RPM 1288 x 868 x 961 940
C90 620 E 404 kW (550 HP) 2530 RPM 1288 x 868 x 961 940
C90 620 E 368 kW (500 HP) 2530 RPM 1288 x 868 x 961 940
C90 620 E 331 kW (450 HP) 2530 RPM 1288 x 868 x 961 940
C13 500 382 kW (520 HP) 2000 RPM 1465 x 1000 x 1058 1345
C13 500 367 kW (500 HP) 2000 RPM 1465 x 1000 x 1058 1345
C13 825 E 551 kW (750 HP) 2400 RPM 1465 x 1000 x 1058 1395
C13 825 E 478 kW (650 HP) 2400 RPM 1465 x 1000 x 1058 1395
C13 825 E 441 kW (600 HP) 2400 RPM 1465 x 1000 x 1058 1395
C16 600 441 kW (600 HP) 1800 RPM 1465 x 1000 x 1160 1570
C16 600 404 kW (550 HP) 1800 RPM 1465 x 1000 x 1160 1570
C16 600 368 kW (500 HP) 1800 RPM 1465 x 1000 x 1160 1570
C16 1000 735 kW (1000 HP) 2300 RPM 1465 x 1136 x 1160 1640
C16 1000 662 kW (900 HP) 2300 RPM 1465 x 1136 x 1160 1640
C16 1000 599 kW (815 HP) 2300 RPM 1465 x 1136 x 1160 1640
C16 1000 551 kW (750 HP) 2300 RPM 1465 x 1136 x 1160 1640
C16 1000 478 kW (650 HP) 2300 RPM 1465 x 1136 x 1160 1640

Pleasure Rating

Model A1 A2 B C Dimension (mm) Weight (kg)
S30 230 E 169 kW (230 HP) 4000 RPM 780 x 775 x 753 330
N40 250 E 184 kW (250 HP) 2800 RPM 850 x 708 x 785 490
N40 250 E 169 kW (230 HP) 2800 RPM 850 x 708 x 785 490
N45 100 74 kW (100 HP) 2800 RPM 811 x 700 x 836 450
N60 400 E 294 kW (400 HP) 3000 RPM 1072 x 739 x 778 595
N60 400 E 272 kW (370 HP) 3000 RPM 1072 x 739 x 778 595
N67 150 110 kW (150 HP) 2800 RPM 1052 x 705 x 910 530
N67 220 162 kW (220 HP) 2800 RPM 1072 x 749 x 800 605
N67 280 206 kW (280 HP) 2800 RPM 1072 x 749 x 800 605
N67 450 N 331 kW (450 HP) 3000 RPM 1089 x 724 x 788 600
N67 450 N 309 kW (420 HP) 3000 RPM 1089 x 724 x 788 600
N67 550 404 kW (550 HP) 3200 RPM 1089 x 850 x 825 721
N67 550 368 kW (500 HP) 3200 RPM 1089 x 850 x 825 721
N67 570 EVO 419 kW (570 HP) 3000 RPM 1089 x 850 x 825 721
N67 570 EV0 404 kW (550 HP) 3000 RPM 1089 x 850 x 825 721
N67 570 EV0 390 kW (530 HP) 3000 RPM 1089 x 850 x 825 721
C90 620 E 456 kW (620 HP) 2530 RPM 1288 x 868 x 961 940
C90 620 E 426 kW (580 HP) 2530 RPM 1288 x 868 x 961 940
C90 620 E 404 kW (550 HP) 2530 RPM 1288 x 868 x 961 940
C90 650 E 478 kW (650 HP) 2530 RPM 1288 x 868 x 961 940
C90 650 EVO 478 kW (650 HP) 2530 RPM 1218 x 881 x 984 1014
C90 650 EVO 460 kW (625 HP) 2530 RPM 1218 x 881 x 984 1014
C13 825 E 607 kW (825 HP) 2400 RPM 1465 x 1000 x 1058 1395
C13 825 E 551 kW (750 HP) 2400 RPM 1465 x 1000 x 1058 1395
C16 1000 735 kW (1000 HP) 2300 RPM 1465 x 1136 x 1160 1640
C16 1000 662 kW (900 HP) 2300 RPM 1465 x 1136 x 1160 1640
C16 1000 599 kW (815 HP) 2300 RPM 1465 x 1136 x 1160 1640



Rating Definition
A1 High performance crafts Full throttle operation restricted within 10% of total use period. Cruising speed at engine rpm <90% of rated speed setting. Maximum usage 300 hours per year
A2/B1 Pleasure/commercial vessels Full throttle operation restricted within 10% of total use period. Cruising speed at engine rpm <90% of rated speed setting. Maximum usage 1000 hours per year
B Light duty Full throttle operation restricted within 10% of total use period. Cruising speed at engine rpm <90% of rated speed setting. Maximum usage 1500 hours per year
C Medium duty Full throttle operation <25% of use period. Cruising speed at engine rpm <90% of rated speed setting. Maximum usage 3000 hours per year
D Heavy duty up to 100% of time unlimited h/y





To download the Brochure , please click .
